MAudio DMP3 Dual Microphone/Instrument Preamp

FEATURES:
• 2-channel preamp with XLR microphone inputs and 1/4" instrument inputs accommodates any type of audio signal
• Balanced outputs on TRS jacks deliver hum-free professional audio
• Low harmonic distortion (THD+N: .0005% @ 20Hz-20kHz) for ultra-clean sound
• Exceptional dynamic range to capture all the nuances of your music
• 20Hz to 80kHz frequency response (+/- 0.5dB) ideal for high-resolution recording
• High and low gain range controls offer up to 67dB of gain
• Clip LED for visual feedback of detrimental levels
• Low-cut filters remove unwanted rumble and hum
• Phantom power to accommodate all types of microphones
• Phase reverse switch on each channel ensures optimal recordings

SPECIFICATIONS:
All specs taken at minimum gain unless otherwise stated:
• Frequency response: 20Hz - 80kHz, +/-0.5dB @ max gain
• SNR: -120dB, A-weighted, 20Hz to 20kHz
• THD+N: 0.00035% (-109dB), 20Hz to 20kHz, @ +13.6dBu input
• Max input: +14.6dBu
• Max output: +27.5dBu
• Input impedance: 3k Ohms balanced
• EIN: -128dBm @ 600 Ohms, max gain
• Gain range: 13.5dB to 46.5dB, low gain range
39.5dB to 67.5dB, high gain range
• Low-cut filter: -3dB @ 72Hz (18dB/Octave)
