Pro-Grade AudioM-Track Eight features pristine and precise audio recording with up to 24-bit/96 kHz resolution. Each input channel is equipped with a high-headroom input that features M- Audio's sought-after Octane Preamp Technology. The result is a robust signal path for clean, professional sound. In addition, each input comes with dedicated line-input circuitry so you can record and track with your favorite external preamps.
Improved Monitoring for Better Recording SessionsM-Track Eight offers ultra-low latency monitoring of the input signaleither through the speakers or via headphones. The USB/Analog Direct Balance knob adjusts the balance between the direct inputs and the playback from your computer software for accurate monitoring during tracking and recording sessions. Flexible output routing lets you send signals to outboard gear or analog mixers for summing or processing. Additionally, two headphone outputs, located on the front panel, have their own level and selectable-source controls for creating custom headphone mixes.
Immediate Studio IntegrationIn addition to outstanding audio performance, M-Track Eight connects to your computer via USB 2.0 and easily integrates into your studio with its standard 1U 19" rack size. With a single USB cable, M-Track Eight creates a two-way audio connection with your Mac or PC, enabling you to record directly into your favorite DAW or playback audio to mix and master your tracks. Plus, Cubase 7 LE comes bundled with M-Track Eight for out-of-the-box music creation and gives you a powerful software environment to record, edit, and bounce down your songs.
FEATURES:• 8-channel USB audio interface
• 8 XLR+1/4" combo inputs with individual metering
• Pristine and precise audio recording with up to 24-bit/96 kHz resolution
• High-headroom inputs with Octane Preamp Technology
• Dedicated line-input circuitry for clean, professional recordings
• 2 front-panel instrument inputs for easy access
• Selectable phantom power (Channels 1-4; 5-8) for using condenser microphones
• Dual headphone outs with selectable source for custom mixes and monitoring
• 8 balanced 1/4" outputs and dedicated control room output
• Zero-latency monitoring with USB/Analog Direct Balance control
• Standard 1U 19" rack size with durable metal construction
• Includes Cubase 7 LE for out-of-the-box music creation and up to 8 channels of simultaneous audio recording
Product Package Contents• M-Track Eight
• USB Cable
• Power Supply
• Software Download Card
• User Guide
• Safety & Warranty Manual
SPECIFICATIONS:Mic Inputs 1-8 (balanced XLR)• Frequency Response 20 Hz - 20 kHz (+0.1 dB)
• Dynamic Range 111 dB (A-weighted)
• Signal-to-Noise Ratio 111 dB (1 kHz, +4 dBu, A-weighted)
• THD+N 0.002% (1 kHz, +4 dBu, -1 dBFS)
• Preamp EIN -132 dBu (max gain, 40 O source, A-weighted); -126 dBu (max gain, 150 O source, unweighted)
• Max Input Level +12 dBu
• Sensitivity -46 dBu
• Gain Range 58 dB
Line Inputs 1-8 (balanced 1/4" TRS)• Frequency Response 20 Hz - 20 kHz (+0.1 dB)
• Dynamic Range 112 dB (A-weighted)
• Signal-to-Noise Ratio 111 dB (1 kHz, +4 dBu, A-weighted)
• THD+N 0.002% (1 kHz, +4 dBu, -1 dBFS)
• Max Input Level +16 dBu
• Sensitivity -13 dBu
• Gain Range 29 dB
Inst Inputs 1-2 (unbalanced 1/4" TS)• Frequency Response 20 Hz - 20 kHz (+0.2 dB)
• Dynamic Range 112 dB (A-weighted)
• Signal-to-Noise Ratio 111 dB (1 kHz, +4 dBu, A-weighted)
• THD+N 0.001% (1 kHz, +4 dBu, -1 dBFS)
• Max Input Level +9 dBu
• Sensitivity -21 dBu
• Input Impedance 1 MO
• Gain Range 30 dB
Monitor Outputs 1-2 (differential-balanced 1/4" TRS)• Frequency Response 20 Hz - 20 kHz (+0.1 dB)
• Dynamic Range 112 dB (A-weighted); 110 dB (A-weighted, with Dim activated)
• THD+N 0.003% (1 kHz, -1 dBFS)
• Maximum Output Level +28 dBu; +8 dBu (with Dim activated)
Line Outputs 1-8 (impedance-balanced 1/4" TRS)• Frequency Response 20 Hz - 20 kHz (+0.1 dB)
• Dynamic Range 113 dB (A-weighted)
• THD+N 0.004% (1 kHz, -1 dBFS)
• Maximum Output Level +10 dBu
• Output Impedance 51 O
General• Power 19 V, 2.37 A, center-positive
• Dimensions (width x depth x height) 19.0" x 5.9" x 1.7"; 48.3 cm x 15 cm x 4.3 cm
• Weight 4.37 lbs.; 1.98 kg
