Multimedia presentations are a snap with a variety of data and video inputs that are capable of showing any type of electronic content. Progressive scan stabilizes video images creating a true, movie-like picture. The PJ1065 is also wall/ceiling mountable for a wider variety of installation settings.
FEATURES:• Professional high-brightness 3,500-lumen projector
• Ensures clear bright presentations in any setting.
• Native 1024x768 XGA resolution:
High resolution delivers superior picture definition.
• Easy setup and auto tuning:
One-touch setup button for fast, easy sync and sharp focus.
• Whisper-mode operations:
Whisper-mode for extended lamp life up to 4,000 hours and low noise output.***
• Displays HD signals:
Including 480i, 480p, 720p and 1080i.
• Progressive scan video:
Reduces flicker and artifacts for stable, clear video images.
• Component video for enhanced video quality
View HD signals and other video signals at maximum performance levels.
• Horizontal and vertical keystone correction
• Square your image from any angle.
• Picture-in-picture capability:
View video and computer data simultaneously for spectacular multimedia presentations.
• RGB-out capability:
Allows you to view projected images on a monitor, too.
• Multiple RGB inputs for greater flexibility:
Connect two computers at once for dynamic presentation.
• GSA Compliant
• Accessories expand your options:
Hard carrying case w/cart function - PRJ-HCA-002
Spare lamp - PRJ-RLC-002
Ceiling/wall mount kit - PM-1065
Extended Express Exchange service - EE-CR-02
TECHNICAL SPECIFICATIONS:• LCD:
Type 1.3" Polysilicon (x3) stripe pixel TFT active matrix
Pixel Format 1024 Horizontal x 768 Vertical
Lens Power, zoom/focus (1:1.3x)
• DISPLAY:
Size 30" to 300" (measured diagonally)
Focus Distance 1.1m to 11.0m (3.6' to 36.0')
Lamp 275W UHB compact, 4,000 hour rating***
Brightness 3,500 Lumens
Contrast Ratio 500:1
• Speakers: Stereo
Power 1.2W x2
• INPUT SIGNAL: Video RGB analog, NTSC, PAL-M, PAL-N, SECAM, 480i, 480p, 720p, 1080i
Sync Separated and composite
Frequency Fh : 15-80kHz; Fv : 56-120Hz
• COMPATIBILITY: PC Analog: from VGA up to SXGA Digital: from VGA up to SXGA
Mac Analog: up to SXGA (may require Mac Adapter) Digital: up to XGA (may require Mac Adapter)
• CONNECTOR: RGB Input 15-pin HD, D-sub (x2)
RGB Output 15-pin HD, D-sub (x1)
DVI Input HD 24 PDVI-D (x1)
Composite Video RCA (x1)
Component Video RCA Jack (x3)
S-Video Mini-Din 4 pin (x1) RCA (x2) and 3.5mm (x1)
Audio In RCA (x2) and 3.5mm (x2); Out 3.5mm (x1)
Control 15-pin D-sub (x1)
USB USB upstream (x1)
• POWER: Voltage 90-132V AC/198-264V AC
Frequency 50-60Hz (universal)
Consumption 415W (typ)
• USER CONTROLS: Basic Standby on/off, menu (left, right, up, down), input, reset, mute, zoom, focus, indicator (lamp, power, temp)
Remote Standby on/off, video, laser, blank, RGB, disk pad, auto, mouse, menu, position, menu select (left, right, up, down), PIP, reset, freeze, magnify (+, -, off), volume (up, down), mute, focus (+, -), zoom (+, -)
OnView Brightness, contrast, V. position, H. position, H. phase, H. size, color balance (red), color balance (blue), aspect ratio, auto, RGB, keystone, blank, mirror, start up, PIP, volume, menu color, language, auto off, sync-on-green
• OPERATING CONDITION: Temperature 32F to 95F (0C to 35C)
Humidity 10% to 85% (non-condensing)
• DIMENSIONS: Physical 289mm x 139mm x 345mm (11.4" x 5.5" x 13.6")
• REGULATIONS UL, FCC-B, c-UL, CE, TUV/GS, CB Report, VCCI, BSMI, PCT
California Prop 65 -
WARNING: Cancer and Reproductive Harm -
www.P65Warnings.ca.gov
