FEATURES:• Processor: 1.25GHz PowerPC G4
System bus 167MHz
• Memory: 256MB of PC2700 (333MHz) DDR SDRAM; supports up to 1GB
• Hard Disk Drive: 40GB Ultra ATA/100
• Optical drive: Combo (DVD-ROM/CD-RW)
• Display 17-inch (16-inch viewable) flat CRT
• Graphics: support ATI Radeon 9200; 32MB dedicated DDR SDRAM video memory
• VGA video mirroring (3): Yes (Apple VGA Display Adapter required, sold separately)
• S-video and composite video output (3): Yes (Apple Video Adapter required, sold separately)
• Ports: Two FireWire 400 ports, three USB 2.0 ports (on computer), two USB 1.1 ports (on keyboard), mini-VGA output port, headphone jack, audio line in jack
• Networking: Built-in 10/100BASE-T Ethernet and 56K V.92 modem (4)
• Wireless Networking (1): AirPort Extreme ready; internal Bluetooth module available as build-to-order option
• Speakers: Integrated stereo speakers
• System software: Mac OS X version 10.3 "Panther"
• Software: Classic environment, Mail, iChat AV, Safari, Sherlock, Address Book, QuickTime, iLife '05 (includes iTunes, iPhoto, iMovie HD, iDVD, GarageBand), iSync, iCal, DVD Player, AppleWorks, Microsoft Internet Explorer, EarthLink (includes 30 days of free dial-up service with activation), Quicken 2004 for Mac,World Book 2004 Edition, Sound Studio,Tony Hawk's Pro Skater 4, Deimos Rising, Zinio Reader, Apple Hardware Test
• Hardware Accessories: Apple Keyboard, Apple Mouse, modem cable
TECHNICAL SPECIFICATIONS:Processor and memory• 1.25GHz PowerPC G4 processor with Velocity Engine
• 512K on-chip level 2 cache at full processor speed
167MHz system bus
• 256MB of PC2700 (333MHz) DDR SDRAM, expandable up to 1GB; two user-accessible 184-pin DIMM slots support up to 1GB using 256MB or 512MB DIMMs
Storage• 40GB or 80GB Ultra ATA/100 hard disk drive (2)
• Combo drive (DVD-ROM/CD-RW); reads DVDs at up to 12x speed, writes CD-R discs at up to 32x speed, writes CD-RW discs at up to 10x speed, reads CDs at up to 32x speed
Communications:• Built-in 56K V.92 modem (RJ-11 connector) (4)
• Built-in 10/100BASE-T Ethernet (RJ-45 connector)
• Built-in antennas and expansion slot for optional 54-Mbps AirPort Extreme Card (based on IEEE 802.11g; WiFi Certified for 802.11g and 802.11b interoperability) (1)
• Optional internal Bluetooth module
Display• Built-in 17-inch flat CRT (16-inch viewable image size); 0.25-mm dot pitch
Video• Mini-VGA output port (requires Apple VGA Display Adapter sold separately)
• VGA output resolutions:
640 by 480 pixels at 60Hz, 67Hz, 72Hz, 75Hz, 85Hz, 90Hz, 100Hz and 120Hz
800 by 600 pixels at 56Hz, 60Hz, 72Hz, 75Hz, 85Hz, 90Hz, 100Hz and 120Hz
1024 by 768 pixels at 60Hz, 70Hz, 75Hz, 85Hz, 90Hz and 100Hz
1152 by 870 pixels at 75Hz
1280 by 960 pixels at 75Hz
• S-video and composite video output to connect directly to a TV or projector (requires Apple Video Adapter, sold separately)
• Support for video mirroring: external devices display an image identical to that shown on the built-in display
Graphics support• ATI Radeon 9200 graphics processor with AGP 4X support
• 32MB of dedicated Double Data Rate (DDR) SDRAM video memory
• Five screen resolutions: 640 by 480 pixels, 800 by 600 pixels, 1024 by 768 pixels, 1152 by 864 pixels and 1280 by 960 pixels
Peripheral connections• Two FireWire 400 ports; 8 watts shared
• Total of five USB ports: three USB 2.0 ports on computer (up to 480 Mbps); two USB 1.1 ports on keyboard
Audio• Integrated high-performance stereo audio system
• Internal 16-watt digital amplifier
• Headphone jack (headphones not included)
Audio line in jack
• Built-in microphone
Electrical and environmental requirements• Meets ENERGY STAR requirement
• Line voltage: configured for 100-120V AC or 200-240V AC depending on country of use
• Frequency: 50Hz to 60Hz, single phase
• Maximum continuous power: 230W
• Operating temperature: 50 to 95 F (10 to 35 C)
• Storage temperature: -40 to 116 F (-40 to 47 C)
• Relative humidity: 5% to 95% noncondensing
Maximum altitude: 10,000 feet
Size and weight• Height: 15.8 inches (40.6cm)
• Width: 15.8 inches (40.6cm)
• Depth: 17.1 inches (43.3cm)
• Weight: 50 pounds (22.7kg) (5)
