FEATURES:• Processor: 1.33GHz PowerPC G4
• Level 2 Cache: 512K at 1.33GHz
• System bus 133MHz
• Memory: (DDR SDRAM) 256MB PC2100 (266MHz); supports up to 1.25GB; 1 available expansion slot
• Hard drive (2): 60GB ATA/100 4200 rpm
• Optical drive: Slot-Load Combo Drive (DVD/CD-RW)
• Display: 12.1-inch (diagonal) TFT XGA 14.1-inch (diagonal) TFT XGA
• Graphics: support ATI Mobility Radeon 9200 with 32MB of DDR SDRAM
• FireWire: One FireWire 400 port at up to 400 Mbps
• USB: Two USB 2.0 ports at up to 480 Mbps each
• VGA, S-video and composite video output: Video mirroring supports VGA video out to an external display or projector (requires included Apple VGA Video Adapter) and S-video and composite video out to a TV or VCR (requires optional Apple Video Adapter, sold separately).
• Modem (3): Built-in 56K V.92 modem
• Ethernet: Built-in 10/100BASE-T Ethernet
• Wireless support (4): AirPort Extreme built-in; optional internal Bluetooth module available
• System software: Mac OS X version 10.3 Panther
• Software: All models include Mac OS X, Classic environment, Mail, iChat AV, Safari, Sherlock, Address Book, QuickTime, iLife (includes iTunes, iPhoto, iMovie, iDVD (5), GarageBand), iSync, iCal, DVD Player, AppleWorks, Mac OS X Chess, Microsoft Internet Explorer, EarthLink (includes 30 days of free dial-up service with activation), Quicken 2005 for Mac, World Book 2004 Edition, Nanosaur 2, Marble Blast Gold, Microsoft Office 2004 for Mac Test Drive, Zinio Reader, Apple Hardware Test: Service and support 90 days of free telephone support and one-year limited warranty. Product contains documentation. Backup copy of software is provided on CD-ROM.
Internet access 30 days of free dial-up Internet service with EarthLink (North America only) activation. Internet access requires an Internet service account; fees may apply.
• Hardware accessories: Apple VGA Display Adapter, modem cable, power adapter, AC wall plug, power cord, lithium-ion battery
TECHNICAL SPECIFICATIONS:Processor and memory• 1.2GHz or 1.33GHz PowerPC G4 processor with Velocity Engine and 512K on-chip level 2 cache running at 1.2GHz or 1.33GHz
• 133 MHZ system bus
• 256MB of PC2100 (266MHz) DDR SDRAM (256MB built-in and one available SO-DIMM slot) with support for up to 1.25GB
Storage• 30GB or 60GB Ultra ATA hard disk drive (2)
• One of the following optical drives:
Combo Drive (DVD-ROM/CD-RW); writes CD-R discs at up to 24x speed, writes CD-RW discs at up to 16x speed, reads DVD-ROM discs at up to 8x speed, reads CD-ROM discs at up to 24x speed
SuperDrive (DVD-R/CD-RW); writes DVD-R discs at up to 4x speed, reads DVDs at up to 8x speed, writes CD-R discs at up to 16x speed, writes CD-RW discs at up to 8x speed, reads CDs at up to 24x speed.
• Support for external FireWire and USB storage devices
Display• Choice of built-in 12.1-inch or 14.1-inch (diagonal) TFT XGA active-matrix display
• Support for millions of colors at 1024 x 768 pixel resolution
• Support for resolution scaling to 800 x 600 pixel and 640 x 480 pixel resolution with millions of colors
Graphics support• ATI Mobility Radeon 9200 graphics processor with 32MB of dedicated video memory and AGP 4X support
Communications• Built-in 56K V.92 modem (RJ-11 connector) (3)
• Built-in 10/100BASE-T Ethernet (RJ-45 connector)
• Built-in antennas and expansion slot for optional 54 Mbps AirPort Extreme Card; (compliant with 802.11g standard; Wi-Fi Certified for 802.11g and 802.11b interoperability) (4)
• Optional Internal Bluetooth module available as a built-to-order option
Peripheral connections• Two 480 Mbps USB 2.0 ports
One FireWire 400 port at up to 400 Mbps (6)
Audio• 16-bit CD-quality stereo headphone jack
• Built-in stereo speakers
• Built-in microphone
• Support for external USB audio devices such as microphones and speakers
Video• VGA video output for video mirroring on an external display or projector (24-bit color) with included Apple VGA Display Adapter.
• S-video and composite video output to TV or projector (requires Apple Video Adapter, sold separately)
Battery• iBook G4 with 14.1-inch display: 61-watt-hour lithium-ion battery provides up to 6 hours of battery life on a single charge (1)
• Integrated charge indicator LEDs on battery
Keyboard and trackpad• Built-in full-size keyboard with 77 (U.S.) or 78 (ISO) keys, including 12 function keys, 4 arrow keys (inverted "T" arrangement) and embedded numeric keypad
• Solid-state trackpad for precise cursor control; supports tap, double-tap and drag capabilities
Electrical and environmental• Meets ENERGY STAR requirements
• Line voltage: 100V to 240V AC
• Frequency: 50 to 60 Hz
• Operating temperature: 50 to 95 F (10 to 35 C)
• Storage temperature: -13 to 113 F (-25 to 45 C)
• Relative humidity: 20% to 80% noncondensing
• Maximum operating altitude: 10,000 feet
• Maximum storage altitude: 15,000 feet
Size and weight: (14.1-inch model)• Height: 1.35 inches (3.42 cm)
• Width: 12.7 inches (32.3 cm)
• Depth: 10.2 inches (25.9 cm)
• Weight: 5.9 pounds (2.7 kg) (7)
