Chauvet Professional EPIX Bar Linear Wash Light

chauvet professional epixbar
chauvet professional epixbar Chauvet Professional EPIX Bar Linear Wash Light Chauvet Professional EPIX Bar Linear Wash Light Chauvet Professional EPIX Bar Linear Wash Light
Images may show accessories or configurations not packaged with this item.

Be the first to review this product

Unavailable Discontinued or no longer available.
Sorry, this item is discontinued or no longer available from us. We've left this page up for reference only. Check out some of the other great alternatives on this page or click below to see if it can still be found elsewhere.
Buy on Amazon
PIX' Bar is a pixel-mapping linear fixture incorporating 160 brilliant tri-colored SMD LEDs for dynamic video displays. By accepting a direct feed from ArKaos Kling-Net, it eliminates the hassle of pixel-by-pixel programming and intuitively configures images and effects in any orientation. Versatile and resourceful, it can be positioned vertically, horizontally or obliquely and on any side of a mounting structure.

• Controlled via Arkaos Kling-Net which provides fast and easy assignment and control
• A video/pixel mapping system that doesn't require years of experience or technical know-how to design, set-up or operate
• Does NOT require piles of processing, driver and signal distribution equipment to create large scale displays
• Independent system of strip style fixtures that can be used for video and pixel mapping applications with countless layout options
• Tri-color SMD LEDs covered by a smooth diffuser plate give excellent color rendering and wide viewing angles
• Utilizes powerCON in and out connections for power and RJ45 for Kling-Net protocol communication


• Video Source: See PIX Drive 640
• Source: Tri-color 5050 SMD LEDs
• Pixels/Bar: 160 Pixels
• Pixel Pitch: 25 mm
• Display Refresh Rate: 400 Hz
• Video Refresh Rate: 60 fps
• Viewing Angle: 120
• Luminance: 850 NIT
• Input voltage: Auto-ranging 100-240 VAC 50/60 Hz
• Power and current: 132 W, 1.1 A @ 120 V 60 Hz
• Power and current: 125 W, 0.6 A @ 208 V 60 Hz
• Power and current: 138 W, 0.6 A @ 230 V 50 Hz
• Power linking: 8 units @ 120 V / 16 units @ 208 V / 16 units @ 230 V
• Control: Kling-Net protocol via Arkaos MediaMaster Express + Kling-Net
• Size: 4.6 x 39.3 x 5 in (118 x 997 x 126 mm)
• Weight: 11.5 lbs (5.2 kg)
• Mounting Design: Mounting Bracket
• Housing Material: Steel
• Power Connection: Neutrik powerCON
• Control Connection: RJ45
• IP20, dry location
