Chauvet Professional EPIX Drive 642 Processor and Power Supply for EPIX 2.0

This Item Has Been Discontinued
Or Is No Longer Available.

This information only remains here as a reference
for those who need information on this product.

Planet DJ is a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for sites to earn advertising fees by advertising and linking to amazon.com

chauvet professional epixdrive642
chauvet professional epixdrive642 Chauvet Professional EPIX Drive 642 Processor and Power Supply for EPIX 2.0 Chauvet Professional EPIX Drive 642 Processor and Power Supply for EPIX 2.0 Chauvet Professional EPIX Drive 642 Processor and Power Supply for EPIX 2.0
PIX' Drive 642 hosts the processing and power supply for the EPIX' 2.0 product line in one convenient device. It controls up to 16 PIX' Strip 2.0 or 4 PIX' Bar 2.0 easily using Art-Net (3.0 compliant) or Arkaos Kling-Net. Configuration and setup is fast, easy with its built-in LCD display. Additionally, you can manage configuration and software updates with a network-based remote web server.

• Hosts the processing and power supply for the EPIX' 2.0 product line in one convenient apparatus
• Easily control using Art-Net' (3.0 compliant) or ArKaos Kling-Net
• Convenient and compatible with industry-standard Neutrik powerCON in-and-out connectors for power and RJ45 for control
• Fast, easy setup and configuration using built-in LCD display
• Easily manage configuration and software updates with the network-based remote web server
• Controls up to 16 EPIX' Strip 2.0, or 4 EPIX' Bar 2.0
• Works with Arkaos Media Master Express for a plug-n-play system that requires almost no training to operate

Specifications
• Control Protocols: Art-Net', Kling-Net
• Art-Net' Channels (per output): 480
• Data Connectors: Ethernet (RJ45)
• Device Outputs (RJ45): 4
• IP Rating: IP20, dry location
• Cable Length: 5 ft (1.5 m)
• Power Connection: Edison plug to Neutrik powerCON
• Power Input: Neutrik powerCON
• Power Output: Neutrik powerCON
• Power Linking: 7 units @ 120 V; 10 units @ 208 V; 11 units @ 230 V
• Intended Load: 4 EPIX' Strip 2.0 or 1 EPIX' Bar 2.0 (per device output)
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 232 W, 1.92 A @ 120 V, 60 Hz
• Power and Current: 272 W, 1.32 A @ 208 V, 60 Hz
• Power and Current: 276 W, 1.20 A @ 230 V, 50 Hz
• Weight: 5.6 lb (2.5 kg)
• Dimensions: 8.3 x 10.1 x 3 in (210 x 257 x 78 mm)
• Housing Material: Steel
• Controller (required): Kling-net (via Arkaos Mediamaster software) or Art-net' controller
• Accessories (optional): ArKaos Media Master Express' + KN software
• Approvals: CE, MET
