Chauvet Professional Maverick MK1 Spot Moving Head

Features
• Fully featured 350W LED yoke spot fixture including CMY color mixing, a color wheel, zoom optics, and two gobo wheels, one rotating, and one static
• 16-bit dimming of master dimmer for smooth control of fades
• Variable CMY color mixing system to create a wide pallet of colors
• DMX, WDMX, sACN, and Art-Net for full flexibility of control options
• RDM Enabled for remote addressing and trouble shooting
• 7 to 33 zoom angle for variable beam sizes
• Iris, 3-facet prism, and frost for beam control
• True 1 compatible power input
• Battery backup touchscreen display with auto rotate depending on fixture orientation

Specs

OPTICAL
•Light Source: 1 LED (CW) 350 W, (9.6 A), 6,808 K, 50,000 hours life expectancy
•Beam Angle: 7 to 29
•Field Angle: 7 to 33
•Zoom Angle: 7 to 33
•Illuminance (7): 34,282 lux @ 5 m
•Illuminance (33): 2,097 lux @ 5 m
•Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz

Dynamic Effects
•Pan and Tilt: 540/270
•Pan and Tilt Ranges: 540, 360, 180 pan/270, 180, 90 tilt
•Colors: 7 + white, split colors, continuous scroll at variable speeds
•Colors: CMY flags
•Gobos (1): 7 + open (7 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
•Gobos (2): 7 + open (7 metal), continuous scroll at variable speeds
•Gobo Size (1): Gobo Wheel 1 (rotating): 26 mm (outside), 22 mm (image), 1.2 mm (max. thickness)
•Dimmer: Electronic
•Shutter/Strobe: Electronic
•Zoom: Motorized
•Focus: Motorized
•Frost: Motorized
•Iris: Motorized
•Prism: 3 Facets, motorized, rotating
•Strobe Rate: 0 to 20 Hz
•Move-in-Black: Yes
•Dim Curves: 4

Construction / Physical
•Dimensions: 15.5 x 9.8 x 25.0 in (394 x 250 x 636 mm)
•Weight: 60 lb (27.2 kg)
•Exterior Color: Black
•Housing Material: High-impact flame-retardant polymer

Connections
•Power Connection: Edison plug to Seetronic Powerkon IP65
•Power Input: Seetronic Powerkon IP65
•Data Connectors: 3- and 5-pin XLR
•Cable Length (power): 5 ft (1.5 m)

Control
•Control Protocol: Art-Net, sACN, DMX, W-DMX
•DMX Channels: 22 or 29
•Art-Net Channels: 22 or 29
•Modes/Personalities: 2 personalities (22, 29)

Electrical
•Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
•Power and Current: 592 W, 5.07 A @ 120 V, 60 Hz
•Power and Current: 555 W, 2.74 A @ 208 V, 60 Hz
•Power and Current: 536 W, 2.47 A @ 230 V, 50 Hz

Certifications / Qualifications
•CE, MET
•IP Rating: IP20, dry location

What's Included
•Maverick MK1 Spot
•Seetronic Powerkon IP65 power cord
•Omega bracket with mounting hardware

Optional Accessories
•Professional Clamps: CTC-50HC, CTC-50HCN
•Safety Cable: SC-07
•DMX Cables
•Flight Case: CPSINGLECASEA1
