Features• Fully featured 820 W LED yoke profile fixture including CMY+CTO color mixing, a four blade framing shutter system with rotation, a color wheel, a CRI filter, animation wheel, a 9:1 zoom, two independently layerable prisms, two frosts, a static and a rotating gobo wheel
• 16-bit dimming of master dimmer for smooth control of fades
• Variable CMY + CTO color mixing system to create a wide pallet of colors
• Independently layerable 5 facet linear and 5 facet round prisms for increased prism options
• One rotating and one static gobo wheel for dynamic texture possibilities
• Independent light and medium frosts for beam control
• + or 60 degree rotation framing shutter system to allow for better framing positioning.
• Animation wheel for enhanced visual effects
• Iris for total beam control
• RDM control over DMX for fixture reporting
• 5.9 to 52.7 zoom angle for variable beam sizes
• 3 menu presets and preset cross load for decreased shop setup time
• True 1 compatible power input
• Battery backup display with auto-rotate depending on fixture orientation
SpecificationsOptical
• Light Source: 1 LEDs (CW) 820 W, (24 A), 7,258 K, 50,000 hours life expectancy
• Color Temperature (at full): 7,441 K
• CRI: 74.1
• CRI W / Filter: 91.2
• TLCI: 50.9
• Beam Angle: 5.9 to 52.7
• Field Angle: 7.6 to 61.4
• Zoom Angle: 5.9 to 52.7
• Lumens Source: 51,000
• Lumens Output: 23,000
• Illuminance (5.9): 58,869 lux @ 5 m
• Illuminance (52.7): 1,860 lux @ 5 m
• Illuminance W / CRI Filter (5.9): 38,926 lux @ 5 m
• Illuminance W / CRI Filter (52.7): 1,222 lux @ 5 m
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 15000 Hz
Dynamic Effects
• Pan and Tilt: 540/270
• Pan and Tilt Ranges: 540, 360, 180 pan/270, 180, 90 tilt
• Colors: 6 + white, split colors, continuous scroll at variable speeds
• Colors: CMY flags, CTO flag, CRI filter, color correction
• Gobos (1): 7 + open (7 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobos (2): 9 + open (9 glass), continuous scroll at variable speeds
• Effect Wheel: 1 effect
• Framing Shutters: Yes
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Focus: Motorized
• Frost 1: Light Frost - Motorized
• Frost 2: Medium Frost - Motorized
• Iris: Motorized
• Prism: 5 linear facets, motorized, rotating
• Prism: 5 Circular facets, motorized, rotating
• Strobe Rate: 0 to 25 Hz
• Move-in-Black: Yes
• Dim Curves: 5
Construction / Physical
• Dimensions: 16.10 x 12.20 x 29.43 in (409 x 310 x 748 mm)
• Weight: 76.4 lb (34.7 kg)
• Exterior Color: Black
• Housing Material: High-impact flame-retardant polymer
Connections
• Power Connection: Edison plug to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Data Connectors: 3- and 5-pin XLR, Amphenol XLR Net RJ45 connectors in/out
• Cable Length (power): 5 ft (1.5 m)
Control
• Control Protocol: Art-Net, DMX, W-DMX, sACN
• DMX Channels: 38 or 54
• Art-Net Channels: 38 or 54
• Modes/Personalities: 2 personalities (38, 54)
Electrical
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 1,230 W, 10.34 A @ 120 V, 60 Hz
• Power and Current: 1,190 W, 5.81 A @ 208 V, 60 Hz
• Power and Current: 1,180 W, 5.24 A @ 230 V, 50 Hz
• Power and Current (resting): 120 W, .98 A @ 120 V, 60 Hz
• Power and Current (resting): 126 W, .60 A @ 208 V, 60 Hz
• Power and Current (resting): 127 W, .55 A @ 230 V, 50 Hz
• Breaker Size: F20 A, 250 V
Certifications / Qualifications
• CE, MET, FCC
• IP Rating: IP20, dry location
• Noise Level (ambient): 36.5 dB level @ 1 m
• Noise Level (Full): 62.1 dB level @ 1 m
• Noise Level (Eco): 43 dB level @ 1 m
• Temperature (Ambient): -4 F to 113 F (-20 C to 45 C)
What's Included
• Maverick MK3 Profile
• Seetronic Powerkon IP65 power cord
• 2 Omega brackets with mounting hardware
• Quick Reference Guide
Optional Accessories
• Professional Clamps: CTC-50HC, CTC-50HCN
• Safety Cable: SC-07
• IP Rated Seetronic Powerkon Extensions
• DMX cables
• Flight Case: TBA
• MRUPLOAD software uploader
