Its precision LED optics feature CMY + CTO color mixing and a fast 9:1 zoom ratio that maintains a flat field of focus even when fully wide. Maverick MK3 Profile offers great static, rotating, and animation effects from its 2 gobo wheels (1 rotating, 1 static), animation wheel, 2 independent and overlapping prisms and 2 frost options: super light and medium. Control as you see fit with DMX, sACN, Art-Net or W-DMX.
Optical• Light Source: 1 LEDs (CW) 820 W, (24 A), 5948 K, 50,000 hours life expectancy
• Color Temperature (at full): 5948 K
• Front lens diameter: 147 mm
• CRI: 91.2
• Beam Angle: 6.1 to 53.1
• Field Angle: 7.5 to 55
• Zoom Range: 6.1 to 62.9
• Cutoff Angle: 8.2 to 62.9
• Lumens Source: 41,000
• Lumens Output: 17,000
• Illuminance (6.1): 43,069 lux @ 5 m
• Illuminance (53.1): 1,407 lux @ 5 m
• Selectable PWM: 600 Hz, 1,200 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Control• Control Protocol: Art-Net, DMX, W-DMX, RDM, sACN
• DMX Channels: 38 or 54
• Art-Net Channels: 38 or 54
• Modes/Personalities: 2 personalities (38, 54)
Dynamic Effects• Pan and Tilt: 540/270
• Pan and Tilt Ranges: 540, 360, 180 pan/270, 180, 90 tilt
• Colors: 6 + white, split colors, continuous scroll at variable speeds
• Colors: CMY flags, CTO flag, CRI filter, color correction
• Gobos (1): 7 + open (7 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobos (2): 9 + open (9 glass), continuous scroll at variable speeds
• Gobo Size: Gobo Wheel 1 (rotating): 30 mm (outside), 23 mm (image), 1.1 mm (max. thickness)
• Effect Wheel: 1 effect
• Framing Shutters: Yes
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Motorized
• Focus: Motorized
• Frost 1: Light Frost - Motorized
• Frost 2: Medium Frost - Motorized
• Iris: Motorized
• Prism: 5 Facets, round, motorized, rotating
• Prism: 5 Facets, linear, motorized, rotating
• Strobe Rate: 0 to 25 Hz
• Move-in-Black: Yes
• Dim Curves: 5
Construction / Physical• Dimensions: 16.10 x 12.20 x 29.43 in (409 x 310 x 748 mm)
• Dimensions (shipping size): 27.1 x 25.1 x 19.6 in (690 x 640 x 500mm)
• Weight: 76.4 lb (34.7 kg)
• Weight (shipping weight): 80.5 lb (36.5 kg)
• Exterior Color: Black
• Housing Material: High-impact flame-retardant polymer
Connections• Control Protocol: Art-Net, DMX, W-DMX, RDM, sACN
• DMX Channels: 38 or 54
• Art-Net Channels: 38 or 54
• Modes/Personalities: 2 personalities (38, 54)
Electrical• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 1,260 W, 10.67 A @ 120 V, 60 Hz
• Power and Current: 1,220 W, 5.92 A @ 208 V, 60 Hz
• Power and Current: 1,220 W, 5.32 A @ 230 V, 50 Hz
Certification / Qualifications• CE, MET, FCC
• IP Rating: IP20, dry location
• Temperature (Ambient): -4 F to 113 F (-20 C to 45 C)
What's Included• Maverick MK3 Profile
• Seetronic Powerkon IP65 power cord
• 2 Omega brackets with mounting hardware
• Quick Reference Guide
Optional Accessories• Professional Clamp: CTC-50HC, CTC-50HCN
• Safety Cable: SC-07
• IP Rated Seetronic Powerkon Extensions
• DMX Cables
• Flight Case: TBA
• Upload 08 software uploade
