Ready to go on location for any broadcast setting, onAir IP Panel 3 features a superior quality of white light with high CRI/TLC and TM-30 scores, a smooth 16-bit dimming curve and +/- green adjustment, an emulated redshift, the ability to produce a pop of color to achieve the exact look you are aiming to create, along with built-in customizable effects accessible from the onboard control menu. Easily switch mounting options from Jr Pin to Omega Bracket. Drop-in slot for diffusers and intensifier filters ensures ease of use when changing accessories. Adjustable PWM ensures camera-ready use. An optional 28 VDC input via 3-pin XLR powers the fixture from an external battery pack to add increased flexibility for all of your remote needs. DMX, RDM, CRMX, Art-Net, sACN, and onboard control options make for flexible operation.
Features• Full-spectrum LED linear format soft light panel style fixture for broadcast, film, and special events
• IP65 rating for all weather use indoors or out.
• Linear color temperature presets from 2800 K to 8000 K with high CRI and CQS
• Virtual color wheel with color matched to popular gel colors
• +/- Green adjustment and emulated red-shift via DMX or on-board control
• RDM (Remote Device Management) and CRMX Wireless Control for added flexibility
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
• Virtually silent operation for use in studio applications
• Ultra-smooth 16-bit dimming curves and speeds to complement any lighting scheme.
• Easily switch mounting options from jr pin to omega bracket
• Drop-in slot for diffusers and intensifier filter (sold separately)
• Rugged design for years of rough use in the most extreme conditions.
• Easy to use on-board control with full access to all the features of the fixture without the need for a dedicated controller.
• USB port for fixture software updates
• 28 VDC power input via 3-pin XLR to power the fixture from an external battery pack
SpecficationsOptical
• Light Source: 120 LEDs (tri-color RGB) 1.5 W, (282 mA), 50,000 hours life expectancy.
• Light Source: 120 LEDs (WW) 0.5 W, (113 mA), 50,000 hours life expectancy.
• Color Temperature (range): 2800 to 8000 K
• Color Temperature (at full): 5527K
• CRI (3200 K): 91.2
• Beam Angle (No Optics): 111.3
• Beam Angle (Light Filter): 96.7
• Beam Angle (Medium Filter): 97.8
• Beam Angle (Heavy Filter): 108.2
• Beam Angle (Intensifier Filter): 74.4
• Field Angle (No Optics): 153.9
• Field Angle (Light Filter): 149
• Field Angle (Medium Filter): 158.4
• Field Angle (Heavy Filter): 162
• Field Angle (Intensifier Filter): 135.2
• Lumens (No Optics): 8080
• Lumens (Light Filter): 6896
• Lumens (Medium Filter): 6317
• Lumens (Heavy Filter): 5964
• Lumens (Intensifier Filter): 5498
• Illuminance (No Optics): 143 lux @ 5 m
• Illuminance (Light Filter): 134 lux @ 5 m
• Illuminance (Medium Filter): 110 lux @ 5 m
• Illuminance (Heavy Filter): 91 lux @ 5 m
• Illuminance (Intensifier Filter): 141 lux @ 5 m
• Selectable PWM: 600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Dynamic Effects
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 20 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Dim Curves: 4
• Built-in Automated Programs: Yes
Construction / Physical
• Dimensions: 11.2 x 33.75 x 4.75 in (284.48 x 857.25 x 120.65 mm)
• Weight: 26 lb (12 kg)
• Exterior Color: Black
• Housing Material: Die-Cast Magnesium
Connections
• Power Connection: Edison (Local) plug to Seetronic Powercon IP65
• Power Input: Seetronic Powercon IP65
• Power Output: Seetronic Powercon IP65
• Power Input: 28 VDC, 3-pin IP65 XLR
• Data Connectors: 5-pin IP65 XLR, Seetronic etherCON Compatible
• Cable Length (power): 5 ft (1.5 m)
• Software Connection: Type-C USB
Control
• Control Protocol: Art-Net, sACN, DMX, WDMX, CRMX, RDM
• DMX Channels: 1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended
• Art-Net Channels: 1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended
• Modes/Personalities: 14 personalities (1, 3, 4, 5, 6, 8, 11, 12, 15, 19, 24, XY Basic, XY Extended)
Electrical
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 8 units @ 120 V; 14 units @ 208 V; 16 units @ 230 V
• Power and Current: 167 W, 1.392 A @ 120 V, 60 Hz
• Power and Current: 160 W, 0.823 A @ 208 V, 60 Hz
• Power and Current: 157 W, 0.747 A @ 230 V, 50 Hz
Certifications / Qualifications
• CE, MET, FCC, UKCA
• IP Rating: IP65, temporary outdoor use, with pressure equalizing M12 GORE valve
• Temperature (Ambient): -13 F to 113 F (-20 C to 45 C)
What's Included
• onAir Panel 3 Slim IP
• Seetronic Powercon IP65 power cord
• Omega bracket with mounting hardware
Optional Accessories
• onAir Panel 3 IP Studio Barndoor
• onAir Panel 3 IP 60 deg Honeycomb
• onAir Panel 3 IP 30 deg Honeycomb
• onAir Panel 3 IP Medium, Light and Heavy Filters
• onAir Panel 3 IP Intensifier Filter
• onAir Panel 3 IP Pole Op Yoke
• Professional Clamps : CTC-50HC, CTC-50HCN
• Seetronic Powerkon power linking cables
• 5-pin IP DMX Cables
• Ethernet Cables
