Chauvet Professional Rogue Outcast 1 Beam IP65 Moving Head

Optical
• Light Source: USHIO NSL-300W lamp, 8000 K, 8,000 hours life expectancy
• Color Temperature (at full): 7115 K
• CRI: 73.9
• Beam Angle: 1.2
• Field Angle: 2.1
• Illuminance (total): 154,000 lux @ 15 m

Dynamic Effects
• Pan and Tilt: 540/270
• Pan and Tilt Ranges: 540, 360, 180 pan/270, 180, 90 tilt
• Colors: 14 + white, split colors, continuous scroll at variable speeds
• Gobos: 17 + open (17 metal), continuous scroll at variable speeds
• Dimmer: Motorized
• Shutter/Strobe: Motorized
• Focus: Motorized
• Frost: Motorized
• Prism: 5 Facets, motorized, rotating
• Prism: 8 Facets, motorized, rotating
• Move-in-Black: Yes

Construction / Physical
• Dimensions: 16.23 x 12.2 x 23.19 in (412.2 x 310 x 589.1 mm)
• Weight: 70.2 lb (32 kg)
• Exterior Color: Black
• Housing Material: Aluminum die-cast

Connections
• Power Connection: Edison plug to Seetronic Powerkon IP65 Power Input: Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Data Connectors: 5-pin IP rated
• Cable Length (power): 5 ft (1.5 m)

Control
• Control Protocol: DMX, RDM
• DMX Channels: 16 or 19
• Modes/Personalities: 2 personalities (16, 19)

Electrical
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 451 W, 3.81 A @ 120 V, 60 Hz
• Power and Current: 436 W, 2.09 A @ 208 V, 60 Hz
• Power and Current: 408 W, 1.76 A @ 230 V, 50 Hz

Certifications / Qualifications
• CE, MET
• IP Rating: IP65, temporary outdoor/wet use
• Temperature (Ambient): 14 F to 104 F (-10 C to 40 C)

What's Included
• Rogue Outcast 1 Beam
• Seetronic Powerkon IP65 power cord
• 2 Omega brackets with mounting hardware
• Quick Reference Guide

Optional Accessories
• Professional Clamps : CTC-50HC, CTC-50HCN
• Safety Cable: SC-07
• DMX Cables
• IP Rated Seetronic Powerkon Extensions
