Features:• Fully featured, IP 65 rated, high powered Spot/Beam/Wash combination fixture with an USHIO 400W, 6500K with 6000 hour life expectancy lamp, 2 gobo wheels, 2 layerable prisms, and linear zoom
• Rugged housing designed to withstand the elements in a temporary outdoor setting
• Individually controllable and layerable 6 facet linear and 8 facet round prisms for maximizing visual impact
• Frost and beam flattening options for even light distribution
• Tight 2 narrow beam angle for focused air effects
• Linear zoom of 1 to 15.3 in beam mode, 2.2 to 29.1 in spot mode and 4.9 to 28.3 in wash mode for coverage in any application
• 9 rotating and 13 static gobos for massive visual effect
• DMX and RDM protocol control
• True 1 compatible power input
Optical• Light Source: USHIO NSL-400 W lamp, 6632 K, 6,000 hours life expectancy
• Color Temperature (at full): 6483 K
• Beam Angle: 2.2 to 12.4 (Spot mode)
• Field Angle: 4.3 to 24.3 (Spot mode)
• Cutoff Angle: 5.2 to 29.1 (Spot mode)
• Beam Angle: 1 to 5.2 (Beam mode)
• Field Angle: 1.8 to 12.6 (Beam mode)
• Cutoff Angle: 2.1 to 15.3 (Beam mode)
• Beam Angle: 4.9 to 18 (Wash mode)
• Field Angle: 9.3 to 25.6 (Wash mode)
• Cutoff Angle: 12.4 to 28 (Wash mode)
• Zoom Range (Spot mode): 2.2 to 29.1
• Zoom Range (Beam mode): 1 to 15.3
• Zoom Range (Wash mode): 4.9 to 28.3
• Lumens Source: 14,575
• Lumens Output: 9,263
• Illuminance (4.3): 209326 lux @ 5 m (Spot mode)
• Illuminance (24.3): 5742 lux @ 5 m (Spot mode)
• Illuminance (1.8): 123,124 lux @ 15 m (Beam mode)
• Illuminance (12.6): 3,517 lux @ 15 m (Beam mode)
• Illuminance (9.3): 17,118 lux @ 5 m (Wash mode)
• Illuminance (25.6): 1,570 lux @ 5 m (Wash mode)
Dynamic Effects• Pan and Tilt: 540/260
• Pan and Tilt Ranges: 540, 360, 180 pan/260, 180, 90 tilt
• Colors: 13 + white, split colors, continuous scroll at variable speeds
• Gobos (1): 9 + open (9 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobos (2): 13 + open (13 metal), continuous scroll at variable speeds
• Gobo Size: Gobo Wheel 1 (rotating glass): 15.9 mm (outside), 12 mm (image), 1.1 mm (max. thickness)
• Dimmer: Motorized
• Shutter/Strobe: Motorized
• Zoom: Motorized
• Focus: Motorized
• Frost: Motorized
• Prism: 6 Facets, motorized, rotating
• Prism: 8 Facets, motorized, rotating
• Move-in-Black: Yes
Construction / Physical• Dimensions: 15.91 x 12.20 x 30.16 in (404 x 310 x 766 mm)
• Weight: 83.8 lb (38 kg)
• Exterior Color: Black
• Housing Material: Aluminum die-cast
Connections• Power Connection: Bare-wired to Seetronic Powerkon IP65
• Power Input: Seetronic Powerkon IP65
• Data Connectors: 5-pin IP rated
• Cable Length (power): 5 ft (1.5 m)
Control• Control Protocol: DMX, RDM
• DMX Channels: 20 or 25
• Modes/Personalities: 2 personalities (20, 25)
Electrical• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 514 W, 4.329 A @ 120 V, 60 Hz
• Power and Current: 513 W, 2.501 A @ 208 V, 60 Hz
• Power and Current: 520 W, 2.267 A @ 230 V, 50 Hz
Certifications / Qualifications• CE, MET
• IP Rating: IP65, temporary outdoor/wet use
• Temperature (Ambient): 14 F to 104 F (-10 C to 40 C)
What's Included• Rogue Outcast Hybrid IP
• Seetronic Powerkon IP65 power cord
• 2 Omega brackets with mounting hardware
• Quick Reference Guide
