Rogue' R1 Spot features two gobo wheels, one fully rotating/indexing with interchangeable gobos to fit your custom needs, and one wheel with fixed gobos that is fully and variably scrollable. Rogue' R1 Spot also features incredibly crisp optics with a 16.5-degree beam angle, making any gobo look fantastic and clear, and an 8-color plus white color wheel that is fully and variably scrollable. Rogue' R1 Spot comes ready to rock, featuring industry-standard Neutrik powerCON power input/output connections for power linking, and 3-pin and 5-pin DMX connections for ease of use.
VIDEO
VIDEO
Features: • Bold, bright 140-W LED light engine for punchy, solid beams
• Color wheel with 8 colors, split color ability, and continuous variable-speed scrolling
• Two gobo wheels: one fixed slot scrolling wheel and one rotating, interchangeable, scrolling wheel
• Iris and 3-facet prism for stunning effects
• Neutrik powerCON power input/output connections for power linking
• 3- and 5-pin DMX input/output connections
• Simple and complex DMX channel profiles for programming versatility
Specifications • DMX Channels: 16 or 19
• Data Connectors: 3- and 5-pin XLR
• Light Source: 1 LED (CW) 140 W, (6 A), 8250 K, 50,000 hours life expectancy
• Pan and Tilt: 540/270
• Pan and Tilt Ranges: 180, 360, 540 pan/90, 180, 270 tilt
• Automatic Pan/Tilt Correction: Yes
• Colors: 8 + white, split colors, continuous scroll at variable speeds
• Gobos (1): 7 + open (7 metal), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
• Gobos (2): 8 + open (8 metal), continuous scroll at variable speeds
• Gobo Size: Gobo Wheel 1 (rotating): 27.5 mm (outside), 26 mm (image), 0.8 mm (max. thickness)
• Prism: 3 Facets, motorized, rotating
• Dimmer: Electronic
• Focus: Motorized
• Iris: Motorized
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 22 Hz
• Beam Angle: 16.5
• Illuminance (total): 2,619 lux @ 5 m
• Color Temperature (at full): 8500 K
• IP Rating: IP20, dry location
• Cable Length: 5 ft (1.5 m)
• Power Connection: Edison plug to Neutrik powerCON
• Power Input: Neutrik powerCON
• Power Output: Neutrik powerCON
• Power Linking: 6 units @ 120 V; 12 units @ 208 V; 13 units @ 230 V
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 225 W, 2.0 A @ 120 V, 60 Hz
• Power and Current: 224 W, 1.1 A @ 208 V, 60 Hz
• Power and Current: 220 W, 1.0 A @ 230 V, 50 Hz
• Weight: 36 lb (16.3 kg)
• Dimensions: 11.1 x 14.2 x 17.5 in (282 x 360 x 447 mm)
• Approvals: CE, MET
Check out the rest of the Chauvet Professional ROGUE series!
