Chauvet Professional Synapse 4

chauvet professional synapse4
chauvet professional synapse4 Chauvet Professional Synapse 4
Images may show accessories or configurations not packaged with this item.

Be the first to review this product

Dropships Usually ships direct to you from Chauvet Professional in 1-2 business days
Free Shipping FREE Shipping
VIP Price:
The Synapse 4 functions as an intelligent relay pack to offer an innovative solution to many of the most common hurdles involved in setting up and operating LED fixtures. Designed to control the power sent to individual lighting units, the Synapse 4 can take one powerCON input and branch it into four outputs, each of which can be powered on and off individually. An indispensable tool for fixed installations, the Synapse-4 provides the ability to de-power entire sections of an installation thereby prolonging fixture lifespan, and decreasing overall power consumption, saving energy and money.

Rack, truss or wall mountable, the Synapse 4 also offers flexibility as to how its four outputs can be controlled: 1) via DMX; 2) upon sensing the loss of the DMX signal; or 3) via an internal timer that can be used to specify that individual outputs be turned on/off automatically at certain times of day. As an added convenience, the Synapse-4 includes a 4-port DMX opto-iso, allowing users to easily branch their DMX universe in multiple directions and amplify the signal after a long run.

Chauvet Professional Synapse 4 FeaturesAT A GLANCE
• Controllable powerCON relay pack and DMX optically isolated splitter/amplifier
• Compounds the savings of LED fixtures by completely removing power when not in use
• Individually control all 4 relays via DMX, DMX sensing or internal scheduler for specific on/off times every day
• Optically isolated 5-pin DMX splitter provides an easy hub for running DMX to multiple locations
• Convenient mounting options; rack mount, wall mount or clamped to truss

Chavuet Professional Synapse 4 Specs
• Dimensions: 19 x 7.87 x 1.75 in (483 x 200 x 44.5 mm)
• Weight: 6 lb (2.8 kg)
• Exterior Color: Black
• Rackmount: 1U
• Power Connection: Edison (Local) plug to Neutrik powerCON
• Power Input: Neutrik powerCON
• Power Output: Neutrik powerCON
• Data Connectors: 5-pin XLR
• Cable Length (power): 5 ft (1.5 m)
• Control Protocol: DMX
• DMX Channels: 1 or 4
• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Main breaker size: 20 A, 250 V
• Breaker size per output: 20A, 250 V
• CEIP Rating: IP20, dry location

• Synapse 4
• Neutrik powerCON power cord
