• A completely wireless, IP 65 rated, battery powered Gobo Projector with a cool white LED and manual framing shutters that is controlled by W-DMX, IR remote (not included), or manually from the OLED display
• Zoom range of 20 to 41 making sizing patterns on surfaces easy
• Hard and soft focuses are easily achieved
• Works with both glass and metal E size gobos (1 mm max thickness)
• User selectable PWM settings to ensure flawless on camera operation
• M12 hole for easy clamp installation
• Up to 8 hours of operational time on full charge
• Recharging case can be power linked to save on power outlets
• Recharging case can be charged with the lid closed saving warehouse space
Optical• Light Source: 1 LED (CW) 25.2 W, (1.3 A), 6542 K, 50,000 hours life expectancy.
• Color Temperature (at full): 6542 K
• Lumens: 2892
• CRI: 79.1
• Beam Angle:17.3 to 36.6
• Field Angle: 20 to 41
• Zoom Angle: 20 to 41
• Illuminance (17.3): 1,487 lux @ 5 m
• Illuminance (8 hr mode 17.3): 1,487 lux @ 5 m
• Illuminance (36): 347 lux @ 5 m
• Illuminance (P/S mode 36): 165 lux @ 5 m
• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Dynamic Effects• Manual Tilt: 180
• Tilt Ranges: 0 to 180 tilt
• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Zoom: Manual
• Focus: Manual
• Strobe Rate: 0 to 25 Hz
• Dim Modes: 4
• Built-in Automated Programs: Yes
Construction / Physical• Dimensions (Single Unit): 10.11 x 6.81 x 12 in (257 x 173 x 305 mm)
• Dimension (Charging Case): 27.64 x 17.24 x23.36 in (702mm x 438 x 593.4 mm)
• Weight (Single Unit): 6.6 lb (3 kg)
• Weight (Charging Case): 71 lb (32.21 kg)
• Exterior Color: Black
• Housing Material (Single Unit): Aluminum diecast
• Housing Material (Charging Case): Aluminum alloy, wood
• Gobo Size (Optional): "E": 37.5 mm (outside), 24 mm (image), 1 mm (max. thickness)
Connections• Power Connection: Edison (Local) plug to Seetronic Powerkon
• Power Input: Seetronic Powerkon
• Cable Length (power): 5 ft (1.5 m)
Control• Control Protocol: W-DMX, IRC
• DMX Channels: 1, 2, 3 or 6
Electrical• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power Linking: 9 units @ 120 V; 15 units @ 208 V; 16 units @ 230 V
• Power and Current (single unit charging): 42 W, .345 A @ 120 V, 60 Hz
• Power and Current (charging case): 168 W, 1.38 A @ 120 V, 60 Hz
• Power and Current (single unit charging): 48 W, 0.220 A @ 208 V, 60 Hz
• Power and Current (charging case): 192 W, 0.880 A @ 208 V, 60 Hz
• Power and Current (single unit charging): 49 W, 0.211 A @ 230 V, 50 Hz
• Power and Current (charging case): 196 W, 0.844 A @ 230 V, 50 Hz
Battery• Battery type: Lithium Ion
• Rechargeable: Yes
• Battery Charge Time: 8 hours
• Battery Life: 5 hrs (high output), 8 (power saving mode)
• Battery Power: 29.6, 4400 mAh
Certifications / Qualifications• CE, MET
• IP Rating: IP65, temporary outdoor/wet use
What's Included• (4) WELL Gobo
• Charging Case
• powerCON power cable with Edison plug
• (4) Gobo holder
