The versatile ELX112 passive loudspeaker is a compact, powerful choice with real stage presence, for sound reinforcement and stage monitoring applications.
FEATURES:• Designed for House of Worship, Pro Music, and other applications.
• 12" woofer and 1.5" high-frequency titanium compression driver
• 55 Hz - 20 kHz frequency range 94 dB SPL sensitivity; 132 dB max SPL
• 250 W continuous and 1000 W peak power handling
• Rugged wood cabinet pole-mounts or stacks with Live X Subwoofers
SPECIFICATIONS:• Axial Sensitivity 94 dB
• Case Material 9-ply, 15mm Plywood, Internally Braced, with Texured Paint
• Frequency Response (-3 dB) 82 Hz - 18 k Hz
• Frequency Response (-10 dB) 55 Hz - 20 k Hz
• Recommended High-Pass Frequency 45 Hz
• Max. SPL/1m (calc) 132 dB
• Coverage
(Nominal -6 dB) H 90
• Coverage
(Nominal -6 dB) V 50
• LF Transducer (1) EVS-12K, 305mm (12") Woofer
• HF Transducer DH-1K, 39mm (1.5") Titanium Diaphragm Compression Driver
• Crossover Frequency 2.1 k Hz
• Nominal Impedance (Passive) 8 O
• Minimum Impedance 7 O
• Connector Type Dual NL4
• Grill 18GA Steel with Black Powdercoat
• Height 607 mm (23.9")
• Width 362 mm (14.25")
• Depth 340 mm (13.39")
• Weight Net 15.8 kg (34.83 lbs)
• Shipping Weight 20 kg (44.09 lbs)
