Sold as a pair, the black Electro-Voice EVID 3.2T is a passive two-way loudspeaker designed for voice amplification and background/foreground music reproduction in clubs, restaurants, and retail stores. Weather resistant and magnetically shielded, it can be used indoors or outside in a variety of positions, even next to video monitors. Each EVID 3.2T is equipped with dual 3.5" woofers and a 0.75" titanium tweeter, yielding a frequency range of 85 Hz to 20 kHz, and a continuous program power capacity of 150W.
The integrated transformer allows the EVID 3.2T to be driven by 70V or 100V power amplifiers (available separately). Full-bandwidth overload protection ensures reliable operation without additional external circuitry. The standard Euroblock connector enables simple and secure wiring. The EVID 3.2T features a durable, paintable ABS enclosure with a zinc-coated grille to protect all internal components. The included SAM (Strong-Arm-Mount) accommodates multiple mounting positions, and allows for a high degree of horizontal and vertical directivity.
VIDEO
FEATURES: • Designed for Commercial Sound/Life Safety, and other applications.
• Two-way full range
• Vented LF enclosure
• 0.75" voice coil (titanium diaphragm) with Neodymium magnetic structure
• Full-bandwidth overload protection for HF and LF
• Three-dimensional ellipse (for compact look)
• Magnetically shielded for video applications
• Comes with Strong Arm Mount (SAM') and a hex key
• Suspension insert for SAM'; safety point on rear side
SPECIFICATIONS: Frequency Range (-10 dB) 85 - 20000kHz
Weight Net 52.91oz (1500g)
Depth 6.5" (165mm)
Width 5" (127mm)
Height 9.21" (234mm)
Color White
Chassis Size 3.5" (88.9mm)
Coverage (Nominal -6 dB) H 140
Coverage (Nominal -6 dB) V 100
HF Transducer 0.75-inch
Input Connections Spring Terminal
LF Transducer Two 3.5-inch
Max. SPL/1m (calc) 112dB
Minimum Impedance 6O
Nominal Impedance (Passive) 8O
Power Rating 300W
Sensitivity 1 W/1 m 87dB
Speaker Type Full-Range, Mid-High, Two-Way
System Power Handling (Continuous/Program/Peak) 75//300Watts
Transformer Taps 70 V: 5 W, 100 V:10 W
Weatherized Yes
